Steel wire winder metal with base plate, extra heavy-duty version with 100 kg tensile force, clockwise rotation Read more.
When it comes to safety and durability, you can demand TNO-Delft-tested quality and security. Steel wire winder with a fully enclosed winch housing made of DIN 231 aluminium. The housing of the Steel wire winder is chromate-coated and powder-coated in the standard colour grey, RAL 7032. The drive spindle has a double trapezoidal thread and bearings of nylon and bronze. The winch locks as soon as the (removable) crank is stationary, but also when the tension on the cable is lost. the cable can only be mounted in the right direction. capacity with Ø 3 mm steel wire is approx. 8 metres and with Ø 4 mm steel wire is approx. 4.5 metres
- extra heavy-duty version for long service life
- delivered without steel cable
- only available with clockwise rotation
- maximum tensile force 100 kg
- equipped with transmission, so that the wind gear can be operated smoothly
- suitable for steel wire rope Ø 3 mm, length 8 metres
- suitable for steel wire rope Ø 4 mm, length 4.5 metres
- made of steel
- Supplied with crank
- suitable for roller shutters, drop-screens and screens
- Colour grey - RAL 7032
- dimensions housing 95x155x82 mm (wxhxd)
- base plate dimensions 103x198 mm
