Article number
3175
SKU
7212000
Elsamec mid-motor suitable for Axle/Shaft Ø 42 mm, 48 mm and 60 mm, 177 Nm Read more.
A centre motor is a type of roller shutter motor specially designed for installation on the Axle/Shaft of a spring-loaded roller shutter. These motors are ideal for easy conversion of a manually operated security roller shutter to electric operation.
- suitable for spring shafts with drums Ø 200 to 220 mm
- force 177 Nm
- tensile force ± 170 kg
- power supply 230 V AC
- current consumption 2 A
- power consumption 450 W
- degree of protection IP40
- speed 9 rpm
- suitable for axle/Shaft Ø 42, 48 and 60 mm
