Somfy Venetian blind motor J406 Protect io
349,95 Incl. tax
Add to cart
Somfy Venetian blind motor J406 Protect io
Somfy

Somfy Venetian blind motor J406 Protect io

Somfy J406 io Protect 6 Nm blinds motor with io receiver, hindrance detection, frost protection, tilting and control via TaHoma switch. Read more.

349,95 Incl. tax
In stock
You have 00:00:00 left to complete your order.
  • Fast delivery Delivery within 2 working days
  • Free shipping when spending €100 (in NL)
  • Affiliated to Home shopping guarantee

Product description

Somfy J406 io Protect 6 Nm Venetian blind motor

The Somfy J406 io Protect is a smart 230V Venetian blind motor with integrated io-homecontrol® radio receiver. This makes installation easy and eliminates the need for a separate receiver, saving boxes, cables and hassle.

Specially developed for outdoor blinds, this motor combines convenient control with smart safety features. Thanks to the electronic end adjustment, the upper and lower end points can easily be set with a Transmitter or adjusted later. The Motor is delivered in the lower position, so it is immediately ready for mounting.

The J4 io Protect controls the blind in two functions: up/down and tilting for tilting the slats. This allows for precise control of light incidence. Moreover, the Motor always knows what position the blind is in and can also be controlled via the TaHoma switch.

A big advantage of this motor is the built-in protection. The obstacle detection stops the Motor as soon as an obstacle is detected and briefly reverses the blind. The motor is also equipped with frost protection, which prevents damage to the motor or blind if it is frozen at the bottom.

Automatic recalculation of the upper end point keeps the Slats neatly aligned and the blind always closes nice and tight. This ensures optimum comfort, a longer lifespan and a neat appearance of the system.

Key features

  • Somfy J4 io Protect Venetian blind motor
  • Suitable for outdoor blinds
  • Integrated io-homecontrol® radio receiver
  • Up/down and tilting control
  • Controllable with Somfy io transmitters
  • Compatible with TaHoma switch
  • Suitable for sun and wind functions
  • Recommended sensors: Somfy Soliris io and Eolis io
  • Obstacle detection with short return
  • Frost protection in case of frozen shutter
  • Electronic end-point adjustment
  • End points adjustable via Transmitter
  • Automatic calibration of the upper end point
  • My-position adjustable
  • Suitable for U and N mounting
  • Quick connection via STAS3/Hirschmann plug
  • Detachable 0.5 metre cable
  • Protection class IP54

Technical specifications

  • force 6 Nm
  • speed 24 rpm
  • power supply 230V / 50Hz
  • power during operation 95 W
  • standby consumption 0.45 W
  • current 0.4 A
  • frequency 868.300 MHz / 868.950 MHz
  • range in open space approximately 200 metres
  • memory capacity of 9 controls
  • electronic final adjustment
  • final adjustment capacity 200 revolutions
  • noise level 53 dB
  • protection class IP54
  • connection cable 3x 0.75 mm² RRF black
  • fitted with black Hirschmann plug
  • operating temperature -20 °C to +70 °C
  • dimensions 380 x 55 x 78 mm
  • weight 1,5 kg
